DigiTech Whammy 5 MonoNeon Signature Pitch Shift Guitar Pedal

The MonoNeon Signature Whammy is DigiTech’s boldest and most expressive Whammy yet, created in collaboration with the sensational bass virtuoso MonoNeon. Packed with ground breaking features, it builds on the Whammy V while introducing the new Hypersonic Mode for a 3-octave pitch rise, an innovative Octave Blend, and the reimagined Detune for rich, otherworldly textures. With its vibrant design and cutting-edge capabilities, this Whammy redefines pitch-shifting and invites players into an entirely new sonic universe.

        Key Features:

• Hypersonic Setting – The Expression Pedal lets you pitch shift up 3 full octaves
• New Octave Blend and Detune Settings – Mix your original signal with a detuned copy creating a thick layered effect
• Optimized for Guitar and Bass – Designed to work seamlessly with both guitar and bass, delivering optimal sound for each.


  Specifications:

            Input / Output

  • Instrument Input Type: Unbalanced ¼” TS phone jack
  • Max Input Level: +5 dBu
  • Input Impedance: 1 MΩ
  • MIDI Input: 5-Pin DIN
  • Output Type: Unbalanced ¼” TS phone jack
  • Max Output Level: +10 dBu
  • Output Impedance: 1 kΩ

            Electronics

  • Frequency Response: 20 Hz to 20 kHz
  • Signal to Noise Ratio: >105 dB (A-weighted); ref = max level, 22 kHz bandwidth
  • THD: 0.004% @ 1 kHz; ref = 1 dBu w/ unity gain
  • Sample Rate: 44.1 kHz
  • A/D Conversion: 24-bit
  • D/A Conversion: 24-bit

            Physical

  • Dimensions: 6.5” (16.51cm) x 7.75” (19.68cm) x 2.5” (6.35cm) (WxDxH)
  • Shipping Weight: 3.8 lbs. (1720g)

            Power

  • Power Consumption: 2.4 W (265 mA @ 9VDC)
  • Power Requirements: 9 VDC External Adapter (center negative)
  • Included Power Adapter: PS0913DC (9V DC @ 1.3 A) center negative
